Laboy Glass Steam Distillation Apparatus Kit Distilling Set with Biomass Flask Essential Oil Extraction Maker Organic Chemistry Lab Glassware Equipment 25pcs

Laboratory Kits

Laboy Glass Steam Distillation Apparatus Kit Distilling Set with Biomass Flask Essential Oil Extraction Maker Organic Chemistry Lab Glassware Equipment 25pcs

Availability: In Stock
  • Vendor:Chemduk
  • Category: Distillation, Distillation apparatus, Essential Oil DIY, Flasks, Laboratory kits
$219.00

Essential Oil Extraction Distillation Kit

Product Description

 Essential Oil Extraction Distillation Kit

  • This is a steam distillation apparatus for producing essential oils. The glassware parts are all made of high quality borosilicate glass and annealed at 800 degree Celsius
  • Essential Oil Extraction Distillation Kit
  • The glass apparatus in this kit are with interchangeable taper joints, the joints are precision grounded with an extra hand grounding process to ensure leak free.
  • Essential Oil Extraction Distillation Kit including:
  1. 500mL single neck round bottom flask, to be filled with water heated by a hot plate as a boiling flask, 1pcs.
  2. 3 way claisen adapter with joints, one of the Top joints is used to connect a addition funnel, the other one is connected with a biomass flask. 1pcs.
  3. 125mL separator funnel with joints at Top and bottom, to be used as an addition funnel in this setup, which can transfer water to the boiling flask if necessary. 2pcs
  4. Biomass flask with Top outer and bottom inner joint. Put plant material which is suitable for steam distillation in the biomass flask. 1pcs.
  5. 3 way distillation adapter with joints, to be used as a distill head in this setup, connects with a west condenser. 1pcs
  6. West condenser with joints and 200mm in jacket length, with 10mm glass hose connection accommodating 8mm I. D. rubber tubing for cold water in and out, condenses the vapor from distillation. 1pcs.
  7. Distillation adapter bent at 105 degree, which connects the condenser and separator funnel. 1pcs.
  8. 500mL flat bottom flask with joints, to be used as receiving flask, 1pcs.
  9. Plastic joint clip for connecting and fixing two glassware parts. 10pcs.
  10. Penny-head glass stopper with joint .2pcs.
  11. 16ft Rubber tubing with 8mm I. D. and 11mm O. D. 1pcs.
  12. Essential Oil Extraction Distillation Kit



glass claisen adapter with 24 40 joints

500mL single neck round bottom flask boiling flask distillation flask

3 way distillation glass adapter 24 40 adapter

3 Way Claisen Adapter

This claisen adapter has two upper outer joint to attach the separatory funnel for adding liquid and the biomass flask.

Essential Oil Extraction Distillation Kit

With one 24/40 lower inner joint to connect the distillation flask,the vapor will

Essential Oil Extraction Distillation Kit

Single Neck Round Bottom Flask

The 500ml round bottom flask with taper joint was used as distillation flask in this apparatus,it can be filled with water and heated by a heating mantle .

Essential Oil Extraction Distillation Kit

As an important part in water distillation apparatus, this flask from laboyglass is made by hand-blowing to ensure uniform wall thickness ,and it was annealed at 800 degree Celsius,can be heated directly in an open flame.

Essential Oil Extraction Distillation Kit

The 3 Way Distillation Flask

The 3 way distillation adapter is used to connect the biomass flask and the west condenser in the distillation apparatus.

Essential Oil Extraction Distillation Kit



125mL separatory funnel with 24/40 joints

24 40 distillation glass adapter bent adatper lab glassware

500mL biomass flask with 24/40 joints

125mL Separatory Funnel with Two Joints

There are two separatory funnels in this kit ,one is used as the addtional funnel with the claisen adapters, the liquid can be filled to the flask through the funnel,

Essential Oil Extraction Distillation Kit

The other one is used to separate the oil and water,which is put on the receiving flask.

Essential Oil Extraction Distillation Kit

Distillation Adapter Bent at 105 degree

This bent distillation adaper is used to connect the west condenser with the separatory funnel.

Essential Oil Extraction Distillation Kit

500mL Biomass Flask with 24/40 Joints

The biomass flask is used to put the plant material for essential oil.

Essential Oil Extraction Distillation Kit

With joints,connecting the distillation flask and the 3 way distillation head.

Essential Oil Extraction Distillation Kit



glass west condenser with 24 40 joints

rubber tubing for distillation apparatus

penny head glass stopper with 24/40 joint

200mm West Condenser

The west condenser with 10mm glass hose connections,cools and condensate the vapor during distillation.

Essential Oil Extraction Distillation Kit

Rubber Tubing for 10mm Hose Connections

The rubber tubing is used to fit the glass hose connections on the west condenser for the cold water in and out.

Essential Oil Extraction Distillation Kit

Penny-head Glass Stopper

The penny-head glass stopper with taper ground inner joint, can be used to fit the ground female joint.

Essential Oil Extraction Distillation Kit



plastic joint clip for 24 40 or 24 29 joints





Polyacetal Conical Joint Clips

The polyacetal joint clips ,Made of polyacetal,Withstand temperatures up to 302 degree F (150 degree C),not resistant to the corrosive gases.
